Setting Up AIOps Tools for Server Monitoring

Updated on Apr 16, 2026
Mila H
11 MINS READ
Table of Contents
set up an AIOps stack for server monitoring

In this tutorial, we want to discover how to set up an AIOps stack for server monitoring. An AIOps stack is a combination of tools that use AI and automation to monitor, analyze, and manage servers. It is a great way to detect issues, predict failures, and automate responses. In this guide, we will use the following tools for the AIOps stack:

  • Metrics: Prometheus, Node Exporter, and Blackbox Exporter.
  • Logs: Loki and Promtail.
  • Visualization and alerting UI: Grafana.
  • Alert routing: Alertmanager.
  • AIOps: A small Python service that fetches Prometheus metrics, detects anomalies, and triggers Alertmanager via webhook.

In this guide, we use Ubuntu 24.04 server from PerLod Hosting, where you can find support for server monitoring with AIOps.

Requirements for AIOps Stack for Server Monitoring

To complete the guide steps, you need a fresh Ubuntu 24.04 VM with 4 vCPU, 8 GB RAM, and 100 GB disk. Also, you must open the required firewall ports, including:

Bash
Prometheus: 9090Alertmanager: 9093Loki: 3100Grafana: 3000Port 22And 80/443, if you use a reverse proxy.

Remember to set the correct timezone on your server:

Bash
sudo timedatectl set-timezone Asia/Dubai

Once you are done, proceed to the next step to install Docker and Docker Compose, which are used for setting up an AIOps stack.

Install Docker and Docker Compose For Setting up an AIOps Stack

Run the system update and install the required packages with the commands below:

Bash
sudo apt updatesudo apt install ca-certificates curl gnupg -y

Add Docker GPG key and repository to your server with the following commands:

Bash
sudo install -m 0755 -d /etc/apt/keyrings curl -fsSL https://download.docker.com/linux/ubuntu/gpg | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpgecho \  "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] \  https://download.docker.com/linux/ubuntu noble stable" \| sudo tee /etc/apt/sources.list.d/docker.list >/dev/null

Again, run the system update and install Docker and Docker Compose with:

Bash
sudo apt updatesudo apt install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin -y

You can add your user to the Docker group with the command below:

Bash
sudo usermod -aG docker $USER

Log out and log in again to apply the changes.

Create AIOps Stack Directory

You must create the AIOps stack directory and the required tools path in it. To do this, you can run the command below:

Bash
sudo mkdir -p /opt/aiops/{prometheus,alertmanager,grafana-provisioning/{datasources,dashboards},loki,promtail,blackbox,anomaly-detector}

Set the correct ownership for the AIOps stack directory with:

Bash
sudo chown -R $USER:$USER /opt/aiops

Switch to the AIOps stack directory:

Bash
cd /opt/aiops

Prometheus Configuration for AIOps Stack

Prometheus is the main monitoring engine. The first step is to configure Prometheus server monitoring by creating the Prometheus YAML file with the following command:

Bash
sudo nano /opt/aiops/prometheus/prometheus.yml

Add the following configuration to the file:

YAML
global:  scrape_interval: 15s  evaluation_interval: 15s alerting:  alertmanagers:    - static_configs:        - targets: ["alertmanager:9093"] rule_files:  - /etc/prometheus/rules/*.yml scrape_configs:  - job_name: "prometheus"    static_configs:      - targets: ["prometheus:9090"]   - job_name: "node-exporters"    static_configs:      # Add your monitored servers' IPs (with :9100) here      - targets: ["10.0.0.11:9100","10.0.0.12:9100"]   - job_name: "blackbox-http"    metrics_path: /probe    params:      module: [http_2xx]    static_configs:      - targets:          - https://example.com          - https://your-api.example    relabel_configs:      - source_labels: [__address__]        target_label: __param_target      - source_labels: [__param_target]        target_label: instance      - target_label: __address__        replacement: blackbox:9115

Also, you can create a simple alert rule in the Prometheus rule file:

Bash
sudo nano /opt/aiops/prometheus/rules/infra.yml

Add the following alert rule to the file:

YAML
groups:- name: infra  rules:  - alert: NodeDown    expr: up{job="node-exporters"} == 0    for: 2m    labels: {severity: critical}    annotations:      summary: "Node down: {{ $labels.instance }}"      description: "No scrape data for 2m."   - alert: HighCPU    expr: 100 - (avg by (instance) (rate(node_cpu_seconds_total{mode="idle"}[5m])) * 100) > 85    for: 5m    labels: {severity: warning}    annotations:      summary: "High CPU on {{ $labels.instance }}"      description: "CPU usage >85% for 5m."   - alert: DiskFilling    expr: (node_filesystem_size_bytes{fstype!~"tmpfs|overlay"} - node_filesystem_free_bytes{fstype!~"tmpfs|overlay"})           / node_filesystem_size_bytes{fstype!~"tmpfs|overlay"} > 0.9    for: 10m    labels: {severity: warning}    annotations:      summary: "Disk >90% on {{ $labels.instance }}"      description: "Filesystem filling up."

Tip: To learn more about Prometheus Linux server monitoring, you can check this guide on Monitoring a Linux host using Prometheus.

Alertmanager Configuration for AIOps Stack

The next step is to set up Alertmanager for server monitoring, which handles notifications from Prometheus. Create the Alertmanager YAML file with:

Bash
sudo nano /opt/aiops/alertmanager/alertmanager.yml

Add the following configuration to the file. You can replace SMTP with real credentials or remove the email if not needed yet:

YAML
route:  receiver: default  group_by: ["alertname", "instance"]  group_wait: 30s  group_interval: 5m  repeat_interval: 3h receivers:- name: default  email_configs:    - to: "alerts@example.com"      from: "aiops@example.com"      smarthost: "smtp.example.com:587"      auth_username: "aiops@example.com"      auth_identity: "aiops@example.com"      auth_password: "CHANGE_ME"  webhook_configs:    - url: "http://anomaly-detector:8080/alertmanager"      send_resolved: true

Loki and Promtail Log Configuration for AIOps Stack

Loki is a log aggregation system, and Promtail is its log collector. Promtail gathers logs from your server and sends them to Loki, which makes it easy to search logs in Grafana alongside metrics.

Create the Loki YAML file with the following command:

Bash
sudo nano /opt/aiops/loki/config.yml

Add the following configuration to it:

YAML
auth_enabled: falseserver:  http_listen_port: 3100common:  path_prefix: /loki  ring:    instance_addr: 127.0.0.1    kvstore:      store: inmemoryschema_config:  configs:  - from: 2024-01-01    store: boltdb-shipper    object_store: filesystem    schema: v13    index:      prefix: index_      period: 24hstorage_config:  boltdb_shipper:    active_index_directory: /loki/index    cache_location: /loki/boltdb-cache  filesystem:    directory: /loki/chunkslimits_config:  ingestion_burst_size_mb: 64  ingestion_rate_mb: 32  max_cache_freshness_per_query: 10mchunk_store_config:  max_look_back_period: 720htable_manager:  retention_deletes_enabled: true  retention_period: 720h

Also, create the Promtail file with the command below:

Bash
sudo nano /opt/aiops/promtail/config.yml

Add the following config to the file:

YAML
server:  http_listen_port: 9080positions:  filename: /positions.ymlclients:  - url: http://loki:3100/loki/api/v1/pushscrape_configs:  - job_name: system-logs    static_configs:      - targets: [localhost]        labels:          job: varlogs          host: ${HOSTNAME}          __path__: /var/log/*.log

Configure Blackbox Exporter for AIOps Stack

Blackbox Exporter checks external endpoints like APIs or websites using HTTP probes, which helps you monitor the availability and response of your web services.

At this point, you can create the Blackbox Exporter YAML file with the following command:

Bash
sudo nano /opt/aiops/blackbox/blackbox.yml

Add the following configuration to the file:

YAML
modules:  http_2xx:    prober: http    http:      preferred_ip_protocol: ip4      no_follow_redirects: false      fail_if_not_ssl: false      fail_if_body_not_matches_regexp:        - ".+"

Grafana Configuration for AIOps Stack

You can connect Grafana to Prometheus and Loki as data sources, and load dashboards to visualize server performance, logs, and alerts in one place.

To create the Grafana data sources YAML file, run the command below:

Bash
sudo nano /opt/aiops/grafana-provisioning/datasources/datasource.yml

Add the following configuration to the file:

YAML
apiVersion: 1datasources:  - name: Prometheus    type: prometheus    url: http://prometheus:9090    access: proxy    isDefault: true  - name: Loki    type: loki    url: http://loki:3100    access: proxy    jsonData:      maxLines: 1000

Optional Note: You can drop JSON dashboards in grafana-provisioning/dashboards/ and add a dashboards.yml provisioning file.

Create the Grafana dashboards YAML file with:

Bash
sudo nano /opt/aiops/grafana-provisioning/dashboards/dashboards.yml

Add the following config to the file:

YAML
apiVersion: 1providers:  - name: 'Default'    orgId: 1    folder: 'AIOps'    type: file    options:      path: /etc/grafana/dashboards

AIOps Microservice: Anomaly Detector Configuration

This custom Python microservice analyzes Prometheus metrics in real time using STL decomposition and z-score detection to identify anomalies. When it detects unusual behavior, it sends a synthetic alert to Alertmanager automatically.

Create the requirements file with the following command:

Bash
sudo nano /opt/aiops/anomaly-detector/requirements.txt

Add the following requirements to the file:

flask==3.0.3requests==2.32.3pandas==2.2.3numpy==2.1.1statsmodels==0.14.3

Then, create the anomaly detector script file with:

Bash
sudo nano /opt/aiops/anomaly-detector/app.py

Add the following script to the file:

Python
from flask import Flask, request, jsonifyimport os, time, requests, jsonimport pandas as pdimport numpy as npfrom datetime import datetime, timedeltafrom statsmodels.tsa.seasonal import STL PROM = os.getenv("PROM_URL", "http://prometheus:9090")ALERTMAN = os.getenv("ALERTMAN_URL", "http://alertmanager:9093/api/v2/alerts")QUERY = os.getenv("PROM_QUERY", '100 - (avg by (instance)(rate(node_cpu_seconds_total{mode="idle"}[5m]))*100)') app = Flask(__name__) def fetch_series(minutes=120, step="30s"):    end = int(time.time())    start = end - minutes*60    url = f"{PROM}/api/v1/query_range"    r = requests.get(url, params={"query": QUERY, "start": start, "end": end, "step": step}, timeout=30)    r.raise_for_status()    return r.json() def stl_anomaly(values):    if len(values) < 60:        return None    ts = pd.Series([float(v[1]) for v in values])    stl = STL(ts, period=60, robust=True).fit()    resid = stl.resid    z = (resid - resid.mean()) / (resid.std() + 1e-9)    if abs(z.iloc[-1]) > 3.5:        return float(ts.iloc[-1]), float(z.iloc[-1])    return None def push_alert(instance, value, zscore):    payload = [{        "labels": {            "alertname": "AIOpsDetectedAnomaly",            "severity": "warning",            "instance": instance        },        "annotations": {            "summary": f"AIOps anomaly on {instance}",            "description": f"Value={value:.2f}, z-score={zscore:.2f} on query: {QUERY}"        }    }]    rr = requests.post(ALERTMAN, data=json.dumps(payload), headers={"Content-Type":"application/json"}, timeout=10)    rr.raise_for_status() @app.route("/run", methods=["POST","GET"])def run():    data = fetch_series()    if data.get("status") != "success":        return jsonify({"status":"error","msg":data}), 500    result = data["data"]["result"]    anomalies = []    for series in result:        metric = series.get("metric", {})        inst = metric.get("instance","unknown")        values = series.get("values", [])        res = stl_anomaly(values)        if res:            val, z = res            push_alert(inst, val, z)            anomalies.append({"instance":inst,"value":val,"z":z})    return jsonify({"status":"ok","anomalies":anomalies}) @app.route("/alertmanager", methods=["POST"])def inbound():    _ = request.json    return jsonify({"status":"received"}), 200 if __name__ == "__main__":    app.run(host="0.0.0.0", port=8080)

Now you must create the Dockerfile in the anomaly detector:

Bash
sudo nano /opt/aiops/anomaly-detector/Dockerfile

Add the following config to the file:

Docker
FROM python:3.11-slimWORKDIR /appCOPY requirements.txt .RUN pip install --no-cache-dir -r requirements.txtCOPY app.py .ENV PROM_URL=http://prometheus:9090ENV ALERTMAN_URL=http://alertmanager:9093/api/v2/alertsENV PROM_QUERY=100 - (avg by (instance)(rate(node_cpu_seconds_total{mode="idle"}[5m]))*100)EXPOSE 8080CMD ["python","/app/app.py"]

Set up AIOps Stack Docker Compose File

At this point, you can easily create the whole stack in a Docker Compose file. Create the file with the command below:

Bash
sudo nano /opt/aiops/docker-compose.yml

Add the following config to the file:

YAML
services:  prometheus:    image: prom/prometheus:v2.55.1    command:      - "--config.file=/etc/prometheus/prometheus.yml"      - "--storage.tsdb.path=/prometheus"      - "--web.enable-lifecycle"    volumes:      - ./prometheus/prometheus.yml:/etc/prometheus/prometheus.yml:ro      - ./prometheus/rules:/etc/prometheus/rules:ro      - prom_data:/prometheus    ports: ["9090:9090"]    restart: unless-stopped   alertmanager:    image: prom/alertmanager:v0.27.0    volumes:      - ./alertmanager/alertmanager.yml:/etc/alertmanager/alertmanager.yml:ro    ports: ["9093:9093"]    restart: unless-stopped   loki:    image: grafana/loki:2.9.8    command: ["-config.file=/etc/loki/config.yml"]    volumes:      - ./loki/config.yml:/etc/loki/config.yml:ro      - loki_data:/loki    ports: ["3100:3100"]    restart: unless-stopped   promtail:    image: grafana/promtail:2.9.8    command: ["-config.file=/etc/promtail/config.yml"]    volumes:      - ./promtail/config.yml:/etc/promtail/config.yml:ro      - /var/log:/var/log      - promtail_positions:/positions.yml    restart: unless-stopped   blackbox:    image: prom/blackbox-exporter:v0.25.0    command: ["--config.file=/etc/blackbox/blackbox.yml"]    volumes:      - ./blackbox/blackbox.yml:/etc/blackbox/blackbox.yml:ro    ports: ["9115:9115"]    restart: unless-stopped   grafana:    image: grafana/grafana:11.2.0    environment:      - GF_SECURITY_ADMIN_PASSWORD=ChangeMe!      - GF_USERS_ALLOW_SIGN_UP=false    volumes:      - grafana_data:/var/lib/grafana      - ./grafana-provisioning/datasources:/etc/grafana/provisioning/datasources:ro      - ./grafana-provisioning/dashboards:/etc/grafana/dashboards      - ./grafana-provisioning/dashboards/dashboards.yml:/etc/grafana/provisioning/dashboards/dashboards.yml:ro    ports: ["3000:3000"]    restart: unless-stopped   anomaly-detector:    build: ./anomaly-detector    environment:      - PROM_URL=http://prometheus:9090      - ALERTMAN_URL=http://alertmanager:9093/api/v2/alerts      - PROM_QUERY=100 - (avg by (instance)(rate(node_cpu_seconds_total{mode="idle"}[5m]))*100)    ports: ["8080:8080"]    restart: unless-stopped volumes:  prom_data:  grafana_data:  loki_data:  promtail_positions:

Once you are done, you can run the anomaly detector with the following commands:

Bash
docker compose build anomaly-detectordocker compose up -d

Check if the service is up and running with the command below:

Bash
docker compose ps

Install Node Exporter on Each Server To Monitor

At this point, you must set up Node Exporter on each server target you want to monitor. It collects CPU, memory, disk, and network metrics and exposes them on port 9100, and then Prometheus scrapes these metrics for analysis and alerting.

To do this, you can run the following commands:

Bash
NODE_EXPORTER_VERSION=1.8.2cd /tmp curl -LO https://github.com/prometheus/node_exporter/releases/download/v${NODE_EXPORTER_VERSION}/node_exporter-${NODE_EXPORTER_VERSION}.linux-amd64.tar.gz tar xzf node_exporter-*.tar.gzsudo mv node_exporter-*/node_exporter /usr/local/bin/sudo useradd --no-create-home --shell /usr/sbin/nologin nodeexp || true

Then, create the systemd service for Node Exporter with the command below:

Bash
sudo tee /etc/systemd/system/node_exporter.service >/dev/null <<'EOF'[Unit]Description=Prometheus Node ExporterAfter=network.target[Service]User=nodeexpGroup=nodeexpType=simpleExecStart=/usr/local/bin/node_exporterRestart=on-failure[Install]WantedBy=multi-user.targetEOF

Enable and start the service with the command below:

Bash
sudo systemctl daemon-reloadsudo systemctl enable --now node_exporter

Verify the 9100 port:

Bash
sudo ss -lntp | grep 9100

You must be sure the Prometheus server can reach server_ip:9100.

Verifying AIOps Stack and Creating Dashboards

It is recommended to confirm that every component of the AIOps stack is running correctly. To verify your setup, open the Prometheus Web UI by navigating to the URL below:

http://your-server-ip:9090

From there, go to Status and then Targets. Make sure all targets show as UP. Also, check the Blackbox Exporter to confirm that your target pages are listed and also show as UP.

For Loki, navigate to the following URL:

http://your-server-ip:3100/ready

It must return ready, which means the service is active.

Then, navigate to the Grafana UI and log in with the default credentials:

http://your-server-ip:3000

In Grafana’s Explore section, select Prometheus and run the query up to confirm metrics are available, then switch to Loki and run the query {job="varlogs"} to verify logs are being collected correctly.

To quickly visualize your metrics, you can create a dashboard in Grafana.

Open Grafana, go to Dashboards and then Import, and enter the dashboard ID 1860 from Grafana.com to import Node Exporter Full and get a detailed view of your servers’ performance.

Alternatively, you can place your own JSON dashboard files in the /opt/aiops/grafana-provisioning/dashboards/ directory, and they’ll automatically appear under the AIOps folder when Grafana starts.

Test Alerts and Validate AIOps Anomalies

After setting up the AIOps stack, it’s important to test that alerts and anomaly detection are working correctly. You can simulate different scenarios to confirm that Prometheus, Alertmanager, and the AIOps anomaly detector respond as expected.

For example, stop the Node Exporter service on a monitored server to test a NodeDown alert after about two minutes.

You can also manually test the AIOps anomaly detection by running the command below:

Bash
curl -X POST http://your-server-ip:8080/run

If the last metric point is an outlier, it sends an AIOpsDetectedAnomaly alert to Alertmanager via webhook.

You can automate this process with a cron job, sidecar container, or Grafana alert rule to call /run periodically and keep continuous anomaly checks active.

That's it, you are done with setting up the AIOps stack for server monitoring.

Conclusion

Setting up an AIOps stack for server monitoring provides proactive insights, automatic anomaly detection, and clear visibility across your entire infrastructure. By combining Prometheus, Grafana, Loki, Alertmanager, and a lightweight Python anomaly detector, you can monitor system health and performance in real time and receive smart alerts.

We hope you enjoy this guide. Subscribe to our X and Facebook channels to get the latest server monitoring guides and tips.

For optimal performance and reliability of your AIOps monitoring stack, it is recommended to use Reliable Dedicated Servers or Flexible VPS hosting.

For further reading:

Learn Server Memory Disaggregation

Deploy PyTorch Model on a VPS Environment

File Integrity Monitoring for Secure Data Integrity

AIOps uses machine learning and data analysis to automatically detect problems, find their causes, and connect related events. It helps reduce unnecessary alerts, fix issues faster, and predict potential system problems before they happen.

The detector regularly checks Prometheus metrics, uses STL and z-score analysis to find unusual patterns, and flags any outliers. When it detects an anomaly, it automatically sends an alert to Alertmanager, which can notify your team through email, Slack, or a webhook.

You can turn this stack into Ansible roles to automate deployments, Helm charts to run it on Kubernetes, and Terraform modules to manage infrastructure automatically with code.
