VPS API Gateway Security involves using an API gateway like Kong, NGINX, or Traefik on a VPS to protect and manage access to your APIs, which acts as a secure entry point that controls all incoming and outgoing API traffic.
In this guide, you will learn to deploy an open-source API access using Kong DB-less mode with strong controls, including TLS, API keys, JWT, rate-limiting, CORS, and IP allowlists. Proceed to the guide steps below to secure API access using API gateways on a VPS.
We’ll use a VPS hosted on Perlod Hosting to display how to secure API access using an API Gateway.
Requirements For VPS API Gateway Security
We assumed you have a fresh Ubuntu 22.04 or Ubuntu 24.04 VPS with a public IP address. You need a domain name that is pointed to your server's IP address, for example, api.example.com.
Also, you need SSH access to your server as a non-root user with sudo privileges.
Run the system update and upgrade with the commands below:
sudo apt update && sudo apt upgrade -y
Install UFW firewall and allow the necessary ports through the firewall with the commands below:
sudo apt install ufw -ysudo ufw default deny incomingsudo ufw default allow outgoingsudo ufw allow OpenSSHsudo ufw allow 80/tcpsudo ufw allow 443/tcp
Enable your firewall and check its status with the commands below:
sudo ufw enablesudo ufw status verbose
Note: If you are using a non-standard SSH port, allow it through the firewall.
For further hardening of server access, you can check this full guide on implementing MFA and RBAC.
Install Docker and Docker Compose on your Ubuntu VPS by using the commands below:
sudo apt install ca-certificates curl gnupg lsb-release -y sudo install -m 0755 -d /etc/apt/keyrings curl -fsSL https://download.docker.com/linux/ubuntu/gpg \ | sudo gpg --dearmor -o /etc/apt/keyrings/docker.gpg sudo chmod a+r /etc/apt/keyrings/docker.gpg echo \ "deb [arch=$(dpkg --print-architecture) signed-by=/etc/apt/keyrings/docker.gpg] \ https://download.docker.com/linux/ubuntu $(lsb_release -cs) stable" \ | sudo tee /etc/apt/sources.list.d/docker.list > /dev/null sudo apt updatesudo apt install docker-ce docker-ce-cli containerd.io docker-buildx-plugin docker-compose-plugin -y
Add your non-root user to the Docker group and then log out and log back in to apply the changes:
sudo usermod -aG docker $USER
Also, you must create the project folders and switch to it with the commands below:
sudo mkdir -p ~/api-gw/kongcd ~/api-gw
We will create a Kong config in ~/api-gw/kong/, and a Compose stack in ~/api-gw/.
Once you are done with these requirements, proceed to the steps below to complete the VPS API Gateway Security with Kong.
Implementing API Security and Routing with a Kong Declarative Config
In this step, you can create a declarative configuration file for Kong, which defines a complete API gateway setup in code.
Create the declarative Kong config file with the command below:
sudo nano ~/api-gw/kong/kong.yml
Add the following configuration to the file:
1_format_version: "3.0"2_transform: true3 4services:5 - name: httpbin6 url: http://httpbin:807 routes:8 - name: httpbin-route9 paths: ["/httpbin"]10 strip_path: true11 1213plugins:14 15 - name: key-auth16 service: httpbin17 config:18 key_names: ["x-api-key"]19 key_in_header: true20 key_in_query: false21 key_in_body: false22 23 24 - name: jwt25 service: httpbin26 config:27 key_claim_name: iss28 secret_is_base64: false29 claims_to_verify:30 - exp31 32 33 - name: rate-limiting34 service: httpbin35 config:36 minute: 6037 policy: local38 fault_tolerant: true39 hide_client_headers: false40 41 42 - name: request-size-limiting43 service: httpbin44 config:45 allowed_payload_size: 146 require_content_length: false47 48 49 - name: ip-restriction50 service: httpbin51 config:52 whitelist:53 - 0.0.0.0/054 55 56 - name: cors57 service: httpbin58 config:59 origins:60 - "https://example.com"61 methods: ["GET", "POST", "OPTIONS"]62 headers: ["Authorization", "Content-Type", "x-api-key"]63 exposed_headers: ["X-RateLimit-Limit-Minute", "X-RateLimit-Remaining-Minute"]64 credentials: false65 max_age: 360066 67consumers:68 69 - username: demo70 71 keyauth_credentials:72 - key: supersecretkey12373 74 jwt_secrets:75 - key: demo-key76 secret: demo-secret
The configuration establishes a service (httpbin) and a route to it, then layers on a robust suite of security plugins to protect the endpoint.
Notes:
- Key-Auth: The client must include this in the request
header: x-api-key: supersecretkey123.
- JWT: The client must send a valid token (HS256) with
iss = demo-key, signed using demo-secret.
- IP Allowlist: Only allow real and trusted IP address ranges.
- CORS: Set the allowed origin to your actual frontend website.
Set up Docker Compose for Kong API Gateway and Demo Backend
At this point, you can create the Docker Compose file, which defines both services, Kong as the gateway and httpbin as the sample API backend, with their networking, dependencies, and configuration. This setup allows you to start the complete gateway ecosystem with all its components using a single command, which ensures consistent deployment across different environments.
Create the Docker Compose stack with the command below:
sudo nano ~/api-gw/docker-compose.yml
Add the following configuration to the file:
1version: "3.9"2 3services:4 httpbin:5 image: kennethreitz/httpbin6 container_name: httpbin7 restart: unless-stopped8 9 kong:10 image: kong:latest11 container_name: kong12 depends_on:13 - httpbin14 environment:15 KONG_DATABASE: "off"16 KONG_DECLARATIVE_CONFIG: /kong/declarative/kong.yml17 KONG_PROXY_LISTEN: "0.0.0.0:8000, 0.0.0.0:8443 ssl"18 19 KONG_ADMIN_LISTEN: "127.0.0.1:8001, 127.0.0.1:8444 ssl"20 KONG_LOG_LEVEL: notice21 volumes:22 - ./kong:/kong/declarative:ro23 ports:24 - "8000:8000"25 - "8443:8443"26 - "127.0.0.1:8001:8001"27 - "127.0.0.1:8444:8444"28 restart: unless-stopped
Run the Composer stack with the command below:
cd ~/api-gwdocker compose up -d
Check for its status that is up and running with the command below:
Run a quick local check with HTTP:
curl -i http://127.0.0.1:8000/httpbin/get
You must receive a 401 Unauthorized error due to the key and JWT requirements.
Enable Automatic HTTPS with Caddy for API Gateway
To securely display the API gateway to the internet, you need HTTPS. You can use Caddy, which automatically obtains and renews free TLS certificates from Let's Encrypt. Caddy acts as a reverse proxy, handles all SSL/TLS termination, and passes the decrypted traffic to Kong on its local port.
Use the following commands to install Caddy:
sudo apt install debian-keyring debian-archive-keyring apt-transport-https -y curl -1sLf 'https://dl.cloudsmith.io/public/caddy/stable/gpg.key' \ | sudo tee /usr/share/keyrings/caddy-stable-archive-keyring.gpg >/dev/null curl -1sLf 'https://dl.cloudsmith.io/public/caddy/stable/debian.deb.txt' \ | sudo tee /etc/apt/sources.list.d/caddy-stable.list >/dev/null sudo apt updatesudo apt install caddy -y
Open and edit the Caddy configuration file with the following command:
sudo nano /etc/caddy/Caddyfile
Edit the config file with:
api.example.com { encode gzip reverse_proxy 127.0.0.1:8000 tls you@example.com}
Enable Caddy and check for its status with the commands below:
sudo systemctl enable caddysudo systemctl reload caddysudo systemctl status caddy --no-pager
Now, you can test HTTPS with the command below:
curl -i https://api.example.com/httpbin/get
You will see an HTTP/2 401 response from Kong because you don't have credentials yet.
Test API Key Authentication
At this point, you can verify that API key security is working by requesting the protected endpoint, but this time we'll include the valid API key in the header. To do this, run the command below:
curl -i https://api.example.com/httpbin/get \ -H 'x-api-key: supersecretkey123'
This should successfully authenticate you and return a 200 OK response from the backend service.
Note: If you hit the rate limit, you’ll see 429 and rate limit headers.
Test JWT Token Authentication
Next, you can test the JWT authentication layer. This requires generating a properly signed JSON Web Token with the correct issuer and expiration time, then using it in an Authorization header. You can use Python and the PyJWT library to create a valid token that Kong will accept for authentication.
Install Python and PyJWT with the commands below:
sudo apt install python3-pip -ypip3 install --user pyjwt
Generate HS256 JWT token with iss=demo-key and a 5-minute expiry with the command below:
python3 - <<'PY'import time, jwtpayload = {"iss":"demo-key","exp":int(time.time())+300}token = jwt.encode(payload, "demo-secret", algorithm="HS256")print(token if isinstance(token, str) else token.decode())PY
Copy the printed token and call the gateway with the following commands:
JWT_TOKEN="paste_the_token_here" curl -i https://api.example.com/httpbin/get \ -H "Authorization: Bearer $JWT_TOKEN"
You must get a 200 OK response.
Implement Mutual TLS (mTLS) for Enhanced Security
For extra security, you can implement mutual TLS (mTLS), which requires clients to present a valid certificate in addition to traditional authentication. This creates a powerful two-factor security model where both the server and client must verify each other's identity.
We want to set up a private Certificate Authority, issue client certificates, and configure Caddy to enforce mTLS validation at the edge.
Generate Certificate Authority and Client Certificates
First, you must create your own Certificate Authority to issue and verify client certificates. You need to generate a private CA keypair, then use it to sign individual client certificates.
The client certificate will be what API consumers present to prove their identity during the TLS handshake.
To do this, run the following commands:
mkdir -p ~/mtls && cd ~/mtls openssl genrsa -out myCA.key 4096openssl req -x509 -new -nodes -key myCA.key -sha256 -days 3650 \ -out myCA.pem -subj "/CN=MyLocalCA" openssl genrsa -out client.key 2048openssl req -new -key client.key -out client.csr -subj "/CN=api-client"openssl x509 -req -in client.csr -CA myCA.pem -CAkey myCA.key -CAcreateserial \ -out client.crt -days 825 -sha256
Then, copy the myCA.pem to /etc/ssl/myca.pem file with the command below:
sudo cp ~/mtls/myCA.pem /etc/ssl/myca.pemsudo chmod 0644 /etc/ssl/myca.pem
Configure Caddy to Enforce Client Certificate Verification
Now you must update the Caddy configuration to require and validate client certificates against your CA. Open the Caddy config file with the command below:
sudo nano /etc/caddy/Caddyfile
Edit the file as shown below:
api.example.com { encode gzip reverse_proxy 127.0.0.1:8000 tls you@example.com { client_auth { mode require_and_verify trusted_ca_cert_file /etc/ssl/myca.pem } }}
Reload Caddy to apply the changes:
sudo systemctl reload caddy
Verify Mutual TLS Enforcement
At this point, test your mTLS setup by making requests both with and without client certificates.
Without client certificates:
curl -i https://api.example.com/httpbin/get
With client cert and key:
curl -i https://api.example.com/httpbin/get \ --cert ~/mtls/client.crt --key ~/mtls/client.key \ -H 'x-api-key: supersecretkey123'
You can also use JWT instead of the API key.
Secure the Kong Admin API from External Access
The Kong Admin API is a powerful management interface that should never be displayed to the public internet. You already configured it to only listen on localhost (127.0.0.1).
KONG_ADMIN_LISTEN: "127.0.0.1:8001, 127.0.0.1:8444 ssl"
In this step, you will learn how to securely access the Admin API when needed using SSH tunneling, which ensures administrative functions remain protected from unauthorized access:
ssh -N -L 8001:127.0.0.1:8001 ubuntu@your-vps
Remember to never show the Admin API publicly.
Operational Best Practices and Maintenance for API Gateway
Running a production API gateway requires ongoing maintenance and monitoring. With these best practices, we want to discuss, you will ensure your gateway remains secure, reliable, and high-performance.
Monitor gateway health and logs with the commands below:
docker compose logs -f kongdocker compose logs -f httpbin curl -sS http://127.0.0.1:8000 | head -n1
Update Kong configuration safely: When you need to change Kong's security rules or routing, you'll modify the kong.yml file and restart the service.
docker compose restart kong
Backup critical configuration files: Regularly back up your Kong declarative config and Caddyfile to version control.
- Keep ~/api-gw/kong/kong.yml in Git.
- Backup /etc/caddy/Caddyfile and /var/lib/caddy/.
Safely upgrade Kong and dependencies: Keeping your gateway components updated is essential for security and feature access.
docker pull kong:latestdocker compose up -ddocker compose ps
Implement strict IP access controls: Replace the permissive IP allowlist with specific, trusted IP ranges from your office, data center, or VPN. This security measure ensures only authorized networks can access your APIs.
1plugins:2 - name: ip-restriction3 service: httpbin4 config:5 whitelist:6 - 203.0.113.0/247 - 2001:db8:abcd::/48
Configure CORS for production security: Proper CORS configuration prevents unauthorized websites from making requests to your API. Always specify exact frontend domain names rather than using wildcards, and regularly review these settings as your application evolves to maintain web security boundaries.
Additional Tips:
Troubleshoot Common Issues in API Gateway Security
Even with proper setup, you may encounter issues from authentication failures to rate limiting. Here are some quick solutions for the most common problems you may face:
1. Let’s Encrypt fails in Caddy:
- Ensure your domain name points to your VPS public IP.
- Configure firewall rules for ports 80 and 443.
- Check for Caddy logs with:
sudo journalctl -u caddy -b --no-pager
2. 401 Unauthorized:
- You may miss or incorrectly
x-api-key or Authorization: Bearer ….
- For JWT: check exp not expired, iss matches demo-key, and secret demo-secret.
3. 429 Too Many Requests: Your rate limit hit; adjust the minute or policy in kong.yml.
4. mTLS handshake errors:
- Client cert not signed by the CA you installed in Caddy.
- client_auth mode set to require_and_verify, and ensure correct trusted_ca_cert_file.
That's it, you are done with VPS API Gateway Security using Kong DB-less mode.
Conclusion
Securing your API with an API gateway is essential to protect sensitive data, prevent abuse, and control traffic. At this point, you have learned to deploy a secure Kong API gateway, add HTTPS automatically with Caddy, set up strong authentication with API keys and JWT, add rate limits, CORS, and optional mTLS.
This setup ensures that only authorized clients can reach your backend APIs, while your infrastructure stays safe and easy to manage.
