High-Performance Reverse Proxy Setup with HAProxy

Updated on Apr 17, 2026
Joey SH
24 MINS READ
Table of Contents
Configure HAProxy as a High-Performance Reverse Proxy

HAProxy is one of the most powerful and open-source TCP/HTTP load balancers and reverse proxy solutions. In this guide, you will learn to install, configure, and optimize HAProxy as a High-Performance Reverse Proxy. If you are running your websites or applications on a VPS or dedicated server from PerLod Hosting, HAProxy is a great way to build a fast and stable reverse proxy in front of your services.

HAProxy operates at both Layer 4 (TCP) and Layer 7 (HTTP) of the OSI model, which offers unprecedented flexibility in traffic management.

  • TCP Mode: In this mode, HAProxy functions as a transparent TCP proxy, forwarding packets between clients and servers without inspecting packet contents.
  • HTTP Mode: When configured in HTTP mode, HAProxy gains full visibility into HTTP messages, enabling advanced features including URL-based routing, header manipulation, cookie insertion, content switching, SSL termination, and session persistence.

Now proceed to the following steps to complete the High-Performance Reverse Proxy Setup with HAProxy.

Requirements for High-Performance Reverse Proxy Setup with HAProxy

Before you start, make sure your server and network match these requirements:

  • A VPS or dedicated server with root or sudo access and supported OS such as Ubuntu 22.04/24.04 or a compatible RHEL-based distro.
  • Open inbound ports including 80/TCP (HTTP) and 443/TCP (HTTPS). Also, you can open 8404/TCP for the HAProxy stats page, which must be restricted by IP or authentication.
  • Allow outbound access from HAProxy to your backend servers, for example, 192.168.1.10:80, 192.168.1.20:8080, etc.
  • If you use HTTPs, you need DNS and SSL.
  • A domain pointing to your HAProxy public IP.
  • If you use certbot --standalone, port 80 must be reachable for HTTP-01 validation.
  • At least one backend web server or app that is reachable from HAProxy.
  • If you enable health checks like /health, make sure your app returns HTTP 200 on that endpoint.

Tip: If you need a high-performance VPS server, you can check PerLod, which offers flexible plans for your needs.

Install HAProxy as a High-Performance Reverse Proxy

HAProxy is available in the official Ubuntu repositories. For production deployments, you can use the PPA repository to access the latest version.

To install the latest HAProxy on Ubuntu 24.04 or 22.04, run the system update and install the software properties management tool with the commands below:

Bash
sudo apt update && sudo apt upgrade -ysudo apt install --no-install-recommends software-properties-common -y

Add HAProxy 3.2 LTS PPA repository with the command below:

Bash
sudo add-apt-repository ppa:vbernat/haproxy-3.2 -y

Run the system update and install HAProxy 3.2 LTS version:

Bash
sudo apt updatesudo apt install haproxy=3.2.* -y

You can also use the default repository to install HAProxy:

Bash
sudo apt updatesudo apt install haproxy -y

Verify the installation by checking its version:

Bash
haproxy -v

On Red Hat-based distributions, HAProxy is available through default repositories via the DNF or YUM package manager.

Install HAProxy on CentOS 8/9 or RHEL 8/9 by using the commands below:

Bash
sudo dnf update -ysudo dnf install haproxy -y

Verify the installation:

Bash
haproxy -v

Check installed package details with the command below:

Bash
rpm -qi haproxy

The installation creates the HAProxy user and group, establishes the configuration directory at /etc/haproxy/, and sets up systemd service management.

Once your installation is completed, enable and start the HAProxy service with the commands below:

Bash
sudo systemctl enable haproxysudo systemctl start haproxy

To verify the HAProxy service is active and running, use the command below:

Bash
sudo systemctl status haproxy

Basic HAProxy Reverse Proxy Configuration

The main HAProxy configuration file is located at /etc/haproxy/haproxy.cfg. In this step, we want to show you a minimal configuration for a reverse proxy setup with two backend web servers.

Before making changes, you must create a backup of the default configuration:

Bash
sudo cp /etc/haproxy/haproxy.cfg /etc/haproxy/haproxy.cfg.backup

Then, edit the HAProxy main config file with the command below:

Bash
sudo nano /etc/haproxy/haproxy.cfg

For a minimal reverse proxy configuration, you can edit the file as shown below:

Bash
#---------------------------------------------------------------------# Global settings#---------------------------------------------------------------------global    # Run HAProxy as unprivileged user for security    user haproxy    group haproxy        # Run as background daemon process    daemon        # Maximum concurrent connections (adjust based on system resources)    maxconn 4096        # Logging configuration - send logs to local syslog    log /dev/log local0    log /dev/log local1 notice        # Chroot to restricted directory for enhanced security    chroot /var/lib/haproxy        # Create stats socket for runtime management    stats socket /var/run/haproxy/admin.sock mode 660 level admin    stats timeout 30s        # SSL/TLS configuration for modern security    ssl-default-bind-ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384    ssl-default-bind-options ssl-min-ver TLSv1.2 no-tls-tickets        # Diffie-Hellman parameter size for SSL    tune.ssl.default-dh-param 2048 #---------------------------------------------------------------------# Common defaults for all proxy sections#---------------------------------------------------------------------defaults    # Operating mode - http enables Layer 7 features    mode http        # Inherit logging configuration from global section    log global        # Enable detailed HTTP request logging    option httplog        # Do not log null connections (health checks, monitoring)    option dontlognull        # Enable HTTP connection close on backend side    option http-server-close        # Add X-Forwarded-For header with client IP address    option forwardfor except 127.0.0.0/8        # Enable redistribution of requests on server failures    option redispatch        # Number of connection retry attempts    retries 3        # Timeout settings for optimal performance and security    timeout connect 10s        # Time to establish backend connection    timeout client 1m          # Maximum client inactivity time    timeout server 1m          # Maximum server response time    timeout http-request 10s   # Maximum time to receive complete HTTP request    timeout http-keep-alive 10s # HTTP keep-alive timeout    timeout check 10s          # Health check timeout    timeout queue 1m           # Maximum time in queue when all servers busy #---------------------------------------------------------------------# Statistics dashboard (optional but recommended)#---------------------------------------------------------------------frontend stats    # Listen on port 8404 for statistics page    bind *:8404        # Enable statistics module    stats enable        # Set statistics URI path    stats uri /stats        # Auto-refresh interval    stats refresh 30s        # Restrict admin access to localhost    acl allowed_network src 127.0.0.1 192.168.1.0/24    stats admin if allowed_network        # Hide HAProxy version for security    stats hide-version        # Set statistics page title    stats realm HAProxy\ Statistics #---------------------------------------------------------------------# Frontend configuration - Client facing proxy#---------------------------------------------------------------------frontend http_front    # Listen on all interfaces, port 80    bind *:80        # Set maximum connections for this frontend    maxconn 2000        # Default backend for unmatched requests    default_backend web_servers #---------------------------------------------------------------------# Backend configuration - Pool of web servers#---------------------------------------------------------------------backend web_servers    # Load balancing algorithm    # Options: roundrobin, leastconn, source, uri, etc.    balance roundrobin        # Enable health checks on all servers    option httpchk GET /        # Expect HTTP 200 response from health checks    http-check expect status 200        # Server definitions    # Format: server <name> <ip>:<port> [options]    server web1 192.168.1.10:80 check inter 3s fall 3 rise 2    server web2 192.168.1.11:80 check inter 3s fall 3 rise 2    server web3 192.168.1.12:80 check inter 3s fall 3 rise 2

After the configuration setup, it is recommended to validate the syntax before restarting HAProxy. Validate configuration file syntax with the command below:

Bash
sudo haproxy -c -f /etc/haproxy/haproxy.cfg

You can use the command below to validate configs with warnings:

Bash
sudo haproxy -c -V -f /etc/haproxy/haproxy.cfg

In your output, you must see:

Bash
Configuration file is valid

If your HAProxy configuration is valid, you can restart it with the command below:

Bash
sudo systemctl restart haproxy

SSL and TLS Termination Configuration for HAProxy

SSL/TLS termination means HAProxy handles the HTTPS encryption and decryption itself, which makes the whole system faster and lets you manage SSL certificates in one central place.

For testing or Let's Encrypt integration, you can generate certificates using Certbot. Install Certbot with the commands below:

Bash
sudo apt install certbot -y # Ubuntu/Debiansudo dnf install certbot -y # CentOS/RHEL

Get the certificates with the command below:

Bash
sudo certbot certonly --standalone -d example.com -d www.example.com

Certificate files are stored in the following locations:

Bash
/etc/letsencrypt/live/example.com/fullchain.pem/etc/letsencrypt/live/example.com/privkey.pem

HAProxy requires certificates in PEM format with the certificate and private key concatenated into a single file. Create a directory for HAProxy certificates:

Bash
sudo mkdir -p /etc/haproxy/certs

Combine the certificate and private key with the following command:

Bash
sudo cat /etc/letsencrypt/live/example.com/fullchain.pem \         /etc/letsencrypt/live/example.com/privkey.pem | \         sudo tee /etc/haproxy/certs/example.com.pem

Set the correct permissions with the commands below:

Bash
sudo chmod 600 /etc/haproxy/certs/example.com.pemsudo chown haproxy:haproxy /etc/haproxy/certs/example.com.pem

Now, open the HAProxy config file and add the following settings after the global and defaults sections. You can place the HTTPS and HTTP frontends before your backend web_servers block:

Bash
#---------------------------------------------------------------------# HTTPS Frontend with SSL Termination#---------------------------------------------------------------------frontend https_front    # Listen on port 443 with SSL enabled    bind *:443 ssl crt /etc/haproxy/certs/example.com.pem alpn h2,http/1.1        # Maximum connections for HTTPS frontend    maxconn 2000        # Add security headers    http-response set-header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload"    http-response set-header X-Frame-Options "SAMEORIGIN"    http-response set-header X-Content-Type-Options "nosniff"    http-response set-header X-XSS-Protection "1; mode=block"    http-response set-header Referrer-Policy "strict-origin-when-cross-origin"        # Set header to indicate HTTPS was used    http-request set-header X-Forwarded-Proto https        # Default backend for HTTPS requests    default_backend web_servers #---------------------------------------------------------------------# HTTP Frontend - Redirect to HTTPS#---------------------------------------------------------------------frontend http_front    bind *:80        # Redirect all HTTP traffic to HTTPS    http-request redirect scheme https code 301 unless { ssl_fc }

For hosting multiple domains, HAProxy supports Server Name Indication (SNI) to select appropriate certificates. Create a certificate bundle directory with the command below:

Bash
sudo mkdir -p /etc/haproxy/certs

Copy all domain certificates to the directory:

Bash
sudo cp domain1.pem /etc/haproxy/certs/sudo cp domain2.pem /etc/haproxy/certs/

In the HAProxy main config file, update frontend configuration:

Bash
frontend https_front    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1

HAProxy automatically selects the appropriate certificate based on the SNI value sent by the client.

HAProxy Load Balancing Algorithms

HAProxy supports multiple load balancing algorithms, which are optimized for different traffic patterns.

1. Round Robin: Distributes requests sequentially across all servers, which gives each server an equal traffic share:

Bash
backend web_servers    balance roundrobin    server web1 192.168.1.10:80 check    server web2 192.168.1.11:80 check    server web3 192.168.1.12:80 check

2. Least Connections: Routes requests to the server with the fewest active connections. It is best for backends with varying request processing times or long-lived connections:

Bash
backend app_servers    balance leastconn    server app1 192.168.1.20:8080 check    server app2 192.168.1.21:8080 check    server app3 192.168.1.22:8080 check

3. Source IP Hash: Routes requests from the same client IP to the same backend server, which provides simple session persistence without cookies:

Bash
backend persistent_servers    balance source    server srv1 192.168.1.30:80 check    server srv2 192.168.1.31:80 check

4. Weighted Distribution: It tells HAProxy to send more traffic to stronger servers and less traffic to weaker ones, based on the weight you set.

Bash
backend weighted_servers    balance roundrobin    # High-capacity server receives 3x traffic    server powerful1 192.168.1.40:80 check weight 300    # Standard servers receive 1x traffic    server standard1 192.168.1.41:80 check weight 100    server standard2 192.168.1.42:80 check weight 100

HAProxy Health Checks

Health checks ensure traffic routes only to operational servers, which maintain high availability.

1. TCP Health Checks: Basic TCP connection check, which verifies the server accepts connections on the specified port:

Bash
backend tcp_servers    mode tcp    balance roundrobin    server srv1 192.168.1.50:3306 check    server srv2 192.168.1.51:3306 check

2. HTTP Health Checks: Advanced health checks using HTTP requests with expected response validation:

Bash
backend http_servers    balance leastconn        # Enable HTTP health checks    option httpchk GET /health        # Expect HTTP 200 status code    http-check expect status 200        # Servers with health check configuration    server web1 192.168.1.60:80 check inter 5s fall 3 rise 2    server web2 192.168.1.61:80 check inter 5s fall 3 rise 2

3. Advanced HTTP Health Checks: Multi-step health checks with custom headers and response validation:

Bash
backend advanced_health    balance roundrobin        option httpchk        # Send custom HTTP health check request    http-check send meth GET uri /api/health ver HTTP/1.1 hdr Host www.example.com        # Expect specific status codes    http-check expect status 200-299        # Validate response contains specific string    http-check expect string "healthy"        server api1 192.168.1.70:8080 check    server api2 192.168.1.71:8080 check

HAProxy Logging Configuration

Logging is how you record what HAProxy is doing, so you can monitor traffic, troubleshoot problems faster, and review events for security checks.

In this step, you can configure your system’s logging service (rsyslog) to collect HAProxy logs into dedicated files, then enable logging inside HAProxy, and finally set up log rotation so the log files don’t fill up your disk.

Create rsyslog configuration for HAProxy with the command below:

Bash
sudo nano /etc/rsyslog.d/49-haproxy.conf

Add the following configuration:

Bash
# Enable UDP syslog reception$ModLoad imudp$UDPServerRun 514$UDPServerAddress 127.0.0.1 # HAProxy logging template$template Haproxy,"%msg%\n" # Log all HAProxy messages to dedicated filelocal0.* -/var/log/haproxy/haproxy.log;Haproxy # Log only notice level and above to admin loglocal0.notice -/var/log/haproxy/haproxy-admin.log;Haproxy # Don't send HAProxy logs to other log files& stop

Create the HAProxy log directory and set appropriate permissions with the commands below:

Bash
sudo mkdir -p /var/log/haproxysudo chown syslog:adm /var/log/haproxy

Restart the rsyslog service and verify that rsyslog is listening:

Bash
sudo systemctl restart rsyslogsudo netstat -ulnp | grep 514

Ensure HAProxy configuration includes logging directives with this config:

Bash
global    log 127.0.0.1:514 local0    log 127.0.0.1:514 local1 notice defaults    log global    option httplog

After restarting HAProxy, logs appear in /var/log/haproxy/haproxy.log.

Create a logrotate configuration with the command below:

Bash
sudo nano /etc/logrotate.d/haproxy

Add rotation policy to the file:

Bash
/var/log/haproxy/*.log {    daily    rotate 14    missingok    notifempty    compress    delaycompress    postrotate        /usr/lib/rsyslog/rsyslog-rotate    endscript}

HAProxy Smart Routing and Blocking Rules: Access Control Lists (ACLs)

ACLs rules in HAProxy let you detect things like the URL path, the domain name (Host header), the visitor’s IP, or the User-Agent, and then route the request to the right backend or block it if needed.

You can define an ACL, then use it with actions like use_backend (route) or http-request deny (block).

Basic ACL Syntax: ACLs consist of a name and a matching condition:

Bash
# ACL format: acl <name> <criterion> [flags] <value> # Check if request path starts with /apiacl is_api path_beg /api # Check if Host header matches domainacl is_domain hdr(host) -i example.com # Check if client IP is in specific rangeacl internal_network src 192.168.1.0/24

Common ACL Use Cases include:

1. Path-Based Routing:

Bash
frontend http_front    bind *:80        # Define ACLs for different paths    acl url_static path_beg /static /images /css /js    acl url_api path_beg /api    acl url_admin path_beg /admin        # Route to different backends based on path    use_backend static_servers if url_static    use_backend api_servers if url_api    use_backend admin_servers if url_admin        # Default backend for unmatched requests    default_backend web_servers

2. IP-Based Access Control:

Bash
frontend secure_front    bind *:443 ssl crt /etc/haproxy/certs/example.com.pem        # Define allowed IP ranges    acl allowed_ips src 192.168.1.0/24 10.0.0.0/8        # Define admin paths    acl admin_path path_beg /admin        # Block admin access from outside allowed IPs    http-request deny if admin_path !allowed_ips        default_backend web_servers

3. Host Header-Based Routing:

Bash
frontend http_front    bind *:80        # Define ACLs for different domains    acl host_app1 hdr(host) -i app1.example.com    acl host_app2 hdr(host) -i app2.example.com    acl host_api hdr(host) -i api.example.com        # Route to different backends    use_backend app1_servers if host_app1    use_backend app2_servers if host_app2    use_backend api_servers if host_api        default_backend web_servers

4. User-Agent Filtering:

Bash
frontend http_front    bind *:80        # Block requests from known bad bots    acl bad_bot hdr_sub(user-agent) -i bot crawler scraper        # Deny bad bot requests    http-request deny if bad_bot        default_backend web_servers

HAProxy Session Persistence (Sticky Sessions)

Session persistence means that once a user is sent to a specific backend server, HAProxy will keep sending that same user back to the same server for future requests. This is important for apps that store user state on one server, because switching servers can log users out.

Cookie-based persistence: In this method, HAProxy adds a small cookie (like SERVERID) to the user’s browser so it can remember which backend server handled the first request.

Bash
backend web_servers    balance roundrobin        # Insert session cookie    cookie SERVERID insert indirect nocache        # Servers with cookie identifiers    server web1 192.168.1.10:80 check cookie web1    server web2 192.168.1.11:80 check cookie web2    server web3 192.168.1.12:80 check cookie web3

Cookie Options:

  • insert: HAProxy inserts the cookie.
  • indirect: Cookie not sent to backend servers.
  • nocache: Prevents caching of responses with cookies.

IP-based persistence (stick tables): In this method, HAProxy remembers the client by IP address and keeps routing that IP to the same backend server, without using cookies. Stick tables are basically an in-memory table that HAProxy uses to store this mapping.

Bash
backend web_servers    balance roundrobin        # Create stick table for IP-based persistence    stick-table type ip size 1m expire 30m        # Track client source IP    stick on src        # Backend servers    server web1 192.168.1.10:80 check    server web2 192.168.1.11:80 check    server web3 192.168.1.12:80 check

Stick Table Parameters:

  • type ip: Use IPv4 addresses as keys.
  • size 1m: Store up to 1,048,576 entries.
  • expire 30m: Entries expire after 30 minutes of inactivity.
  • stick on src: Use client source IP as tracking key.

Rate Limiting and DDoS Protection in HAProxy

Rate limiting protects backend servers from abuse and DoS attacks. It’s a simple but very effective way to reduce abuse and slow down basic DoS/DDoS-style traffic floods.

Basic rate limiting (per IP): Here, HAProxy tracks each client IP and counts how many HTTP requests it makes in the last 10 seconds. If an IP goes above your limit, HAProxy blocks it with HTTP 429 Too Many Requests.

Bash
frontend http_front    bind *:80        # Create stick table to track request rates    stick-table type ip size 1m expire 10s store http_req_rate(10s)        # Track client requests    http-request track-sc0 src        # Deny clients exceeding 20 requests per 10 seconds    http-request deny deny_status 429 if { sc_http_req_rate(0) gt 20 }        default_backend web_servers

Advanced rate limiting (multiple counters): HAProxy tracks several signals at once. If a client looks abusive in any of these metrics, HAProxy flags it and blocks it.

Bash
frontend http_front    bind *:80        # Stick table with multiple counters    stick-table type ip size 200k expire 30s store gpc0,conn_cur,conn_rate(10s),http_req_rate(10s),bytes_out_rate(30s),http_err_rate(10s)        # Track client activity    http-request track-sc1 src        # Define abuse detection ACLs    acl conn_rate_abuse sc1_conn_rate gt 20    acl req_rate_abuse sc1_http_req_rate gt 50    acl err_rate_abuse sc1_http_err_rate gt 20    acl data_rate_abuse sc1_bytes_out_rate gt 20000000        # Mark abuser flag    acl mark_as_abuser sc1_inc_gpc0 gt 0        # Deny abusive clients    http-request deny deny_status 429 if mark_as_abuser req_rate_abuse or conn_rate_abuse or err_rate_abuse or data_rate_abuse        default_backend web_servers

Tarpit (slow down instead of block): A tarpit doesn’t instantly reject the attacker; it intentionally slows them down. This wastes the attacker’s resources and reduces pressure on your backends, while still letting real users through more easily.

Bash
backend slow_down    mode http    timeout tarpit 5s    http-request tarpit    errorfile 500 /etc/haproxy/errors/429.http

You can create the custom error file /etc/haproxy/errors/429.http with these configs:

Bash
HTTP/1.1 429 Too Many RequestsCache-Control: no-cacheConnection: closeContent-Type: text/plainRetry-After: 5 Too Many Requests. Please retry after 5 seconds.

HAProxy Statistics and Monitoring

HAProxy includes a built-in stats dashboard that shows live traffic and backend health, so you can quickly spot overload, failing servers, or unusual spikes. You can enable it by adding a small frontend stats block in your HAProxy config file.

Add statistics frontend to configuration:

Bash
frontend stats    bind *:8404    mode http        # Enable statistics    stats enable        # Set statistics URI    stats uri /stats        # Auto-refresh every 30 seconds    stats refresh 30s        # Restrict access to admin from specific IPs    acl allowed_network src 127.0.0.1 192.168.1.0/24    stats admin if allowed_network        # Hide HAProxy version for security    stats hide-version        # Set authentication (optional)    stats auth admin:SecurePassword123        # Page title    stats realm HAProxy\ Statistics

You can access the statistics page at:

HTML/XML
http://your-server-ip:8404/stats

The statistics dashboard displays essential metrics, including:

  • Session rate
  • Session total
  • Queue current
  • Queue max
  • Server status
  • Health check status
  • Active sessions
  • Bytes transferred
  • Response codes

Runtime API: The Runtime API lets you manage servers live using the admin socket without needing a full reload.

Bash
# Enable Runtime API socketglobal    stats socket /var/run/haproxy/admin.sock mode 660 level admin # Use socat to send commands# Show backend server statusecho "show servers state" | sudo socat stdio /var/run/haproxy/admin.sock # Disable server for maintenanceecho "disable server web_servers/web1" | sudo socat stdio /var/run/haproxy/admin.sock # Enable server after maintenanceecho "enable server web_servers/web1" | sudo socat stdio /var/run/haproxy/admin.sock # Set server to drain mode (finish existing connections, accept no new ones)echo "set server web_servers/web1 state drain" | sudo socat stdio /var/run/haproxy/admin.sock # View statisticsecho "show stat" | sudo socat stdio /var/run/haproxy/admin.sock

HAProxy Performance Tuning

Performance tuning means adjusting both the Linux system and HAProxy settings so they can handle lots of concurrent users without running out of resources or slowing down.

For system-level tuning, you can increase system limits for file descriptors:

Bash
sudo nano /etc/security/limits.conf

Add the following lines to the file:

Bash
haproxy soft nofile 65536haproxy hard nofile 65536

Configure kernel parameters by editing the sysctl configuration:

Bash
sudo nano /etc/sysctl.conf

Add performance parameters to the file:

Bash
# Increase maximum number of connection tracking entriesnet.netfilter.nf_conntrack_max = 262144 # Increase local port rangenet.ipv4.ip_local_port_range = 1024 65535 # Enable TCP fast opennet.ipv4.tcp_fastopen = 3 # Increase maximum backlognet.core.somaxconn = 4096 # Increase TCP max orphansnet.ipv4.tcp_max_orphans = 65536 # Increase max syn backlognet.ipv4.tcp_max_syn_backlog = 20480 # Enable TCP window scalingnet.ipv4.tcp_window_scaling = 1 # Reduce TIME_WAIT socketsnet.ipv4.tcp_fin_timeout = 30

Apply changes with the command below:

Bash
sudo sysctl -p

HAProxy tuning (inside haproxy.cfg): You can tune HAProxy limits so it can actually accept the load:

Bash
global    # Maximum concurrent connections globally    # Formula: (RAM_GB * 1024 * 1024 * 1024) / (16 * 1024) / 2    maxconn 20000        # Number of threads (match CPU core count)    nbthread 4 defaults    # Maximum connections per frontend    maxconn 10000 backend web_servers    # Maximum connections per server    server web1 192.168.1.10:80 check maxconn 500    server web2 192.168.1.11:80 check maxconn 500

Connection pooling (HTTP keep-alive): Enabling keep-alive allows HAProxy to reuse existing HTTP connections instead of opening a new connection for every request. This reduces TCP handshake overhead, lowers backend connection churn, and usually improves throughput and latency:

Bash
defaults    option http-keep-alive    timeout http-keep-alive 10s backend web_servers    option http-keep-alive    server web1 192.168.1.10:80 check

Security Best Practices for HAProxy Setup

At this point, you can follow these security best practices for HAProxy configuration.

1. Firewall Configuration: You can restrict access to HAProxy ports.

Allow HTTP/HTTPS traffic with the command below:

Bash
sudo firewall-cmd --permanent --add-service=httpsudo firewall-cmd --permanent --add-service=https

Allow stats port only from a specific network:

Bash
sudo firewall-cmd --permanent --add-rich-rule='rule family="ipv4" source address="192.168.1.0/24" port protocol="tcp" port="8404" accept'

Then, reload the firewall to apply the changes:

Bash
sudo firewall-cmd --reload

2. Security Headers: You can add security headers to all responses in the HAProxy config file:

Bash
frontend https_front    bind *:443 ssl crt /etc/haproxy/certs/example.com.pem        # Security headers    http-response set-header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload"    http-response set-header X-Frame-Options "DENY"    http-response set-header X-Content-Type-Options "nosniff"    http-response set-header X-XSS-Protection "1; mode=block"    http-response set-header Referrer-Policy "strict-origin-when-cross-origin"    http-response set-header Permissions-Policy "geolocation=(), microphone=(), camera=()"        default_backend web_servers

3. Restricting Access to Sensitive Paths: Implement path-based access restrictions in the HAProxy config file:

Bash
frontend http_front    bind *:80        # Define restricted paths    acl admin_path path_beg /admin    acl api_path path_beg /api        # Define allowed networks    acl internal_network src 192.168.1.0/24 10.0.0.0/8        # Block external access to admin    http-request deny if admin_path !internal_network        default_backend web_servers

Complete Production HAProxy Configuration Example

Here is a full sample HAProxy configuration that combines the most common production best practices in one place:

Bash
#---------------------------------------------------------------------# Global settings - Process-wide configuration#---------------------------------------------------------------------global    # Security: Run as unprivileged user    user haproxy    group haproxy        # Process management    daemon    maxconn 20000    nbthread 4        # Logging    log /dev/log local0    log /dev/log local1 notice        # Security hardening    chroot /var/lib/haproxy        # Runtime API and statistics    stats socket /var/run/haproxy/admin.sock mode 660 level admin expose-fd listeners    stats timeout 30s        # SSL/TLS configuration    ssl-default-bind-ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384    ssl-default-bind-options ssl-min-ver TLSv1.2 no-tls-tickets    ssl-default-server-ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256:ECDHE-ECDSA-AES256-GCM-SHA384:ECDHE-RSA-AES256-GCM-SHA384    ssl-default-server-options ssl-min-ver TLSv1.2    tune.ssl.default-dh-param 2048 #---------------------------------------------------------------------# Default settings for all sections#---------------------------------------------------------------------defaults    mode http    log global    option httplog    option dontlognull    option http-server-close    option forwardfor except 127.0.0.0/8    option redispatch    retries 3    maxconn 10000        # Timeout configuration    timeout connect 10s    timeout client 1m    timeout server 1m    timeout http-request 10s    timeout http-keep-alive 10s    timeout check 10s    timeout queue 1m    timeout tunnel 1h        # Error files    errorfile 400 /etc/haproxy/errors/400.http    errorfile 403 /etc/haproxy/errors/403.http    errorfile 408 /etc/haproxy/errors/408.http    errorfile 500 /etc/haproxy/errors/500.http    errorfile 502 /etc/haproxy/errors/502.http    errorfile 503 /etc/haproxy/errors/503.http    errorfile 504 /etc/haproxy/errors/504.http #---------------------------------------------------------------------# Statistics dashboard#---------------------------------------------------------------------frontend stats    bind *:8404    mode http        stats enable    stats uri /stats    stats refresh 30s    stats hide-version    stats realm HAProxy\ Statistics    stats auth admin:ChangeThisPassword        # Restrict admin access    acl allowed_network src 127.0.0.1 192.168.1.0/24    stats admin if allowed_network #---------------------------------------------------------------------# HTTP Frontend - Redirect to HTTPS#---------------------------------------------------------------------frontend http_front    bind *:80        # Rate limiting    stick-table type ip size 100k expire 30s store http_req_rate(10s)    http-request track-sc0 src    http-request deny deny_status 429 if { sc_http_req_rate(0) gt 100 }        # Redirect all HTTP to HTTPS    http-request redirect scheme https code 301 #---------------------------------------------------------------------# HTTPS Frontend - Main application entry point#---------------------------------------------------------------------frontend https_front    bind *:443 ssl crt /etc/haproxy/certs/ alpn h2,http/1.1        # Rate limiting    stick-table type ip size 100k expire 30s store http_req_rate(10s)    http-request track-sc1 src    http-request deny deny_status 429 if { sc_http_req_rate(1) gt 100 }        # Security headers    http-response set-header Strict-Transport-Security "max-age=31536000; includeSubDomains; preload"    http-response set-header X-Frame-Options "SAMEORIGIN"    http-response set-header X-Content-Type-Options "nosniff"    http-response set-header X-XSS-Protection "1; mode=block"    http-response set-header Referrer-Policy "strict-origin-when-cross-origin"        # Set forwarding headers    http-request set-header X-Forwarded-Proto https    http-request set-header X-Forwarded-Port %[dst_port]        # Path-based routing ACLs    acl url_static path_beg /static /images /css /js /fonts    acl url_api path_beg /api    acl url_admin path_beg /admin        # IP-based access control    acl internal_network src 192.168.1.0/24 10.0.0.0/8        # Block external admin access    http-request deny if url_admin !internal_network        # Route to backends    use_backend static_servers if url_static    use_backend api_servers if url_api    use_backend admin_servers if url_admin        default_backend web_servers #---------------------------------------------------------------------# Main web application backend#---------------------------------------------------------------------backend web_servers    balance leastconn        # Session persistence    cookie SERVERID insert indirect nocache        # Health checks    option httpchk GET /health    http-check expect status 200        # Connection settings    option http-keep-alive        # Servers    server web1 192.168.1.10:80 check inter 3s fall 3 rise 2 maxconn 500 cookie web1    server web2 192.168.1.11:80 check inter 3s fall 3 rise 2 maxconn 500 cookie web2    server web3 192.168.1.12:80 check inter 3s fall 3 rise 2 maxconn 500 cookie web3 #---------------------------------------------------------------------# API backend#---------------------------------------------------------------------backend api_servers    balance roundrobin        # API health checks    option httpchk GET /api/health    http-check expect status 200        # Servers    server api1 192.168.1.20:8080 check inter 5s fall 3 rise 2 maxconn 300    server api2 192.168.1.21:8080 check inter 5s fall 3 rise 2 maxconn 300 #---------------------------------------------------------------------# Static content backend#---------------------------------------------------------------------backend static_servers    balance roundrobin        # Longer timeouts for large file transfers    timeout server 5m        # Basic health check    option httpchk HEAD /        # Servers    server static1 192.168.1.30:80 check inter 10s    server static2 192.168.1.31:80 check inter 10s #---------------------------------------------------------------------# Admin backend#---------------------------------------------------------------------backend admin_servers    balance source        # Sticky sessions based on IP    stick-table type ip size 10k expire 1h    stick on src        # Health checks    option httpchk GET /admin/health    http-check expect status 200        # Server    server admin1 192.168.1.40:8000 check inter 5s

Troubleshooting Common HAProxy Issues

This step helps you quickly troubleshoot the most common HAProxy issues in production.

Issue 1. Service Won't Start: You can check syntax validation and service logs:

Bash
# Validate configurationsudo haproxy -c -f /etc/haproxy/haproxy.cfg # Check systemd logssudo journalctl -u haproxy -n 50 --no-pager # Check service statussudo systemctl status haproxy

Common causes:

  • Syntax errors in the configuration file.
  • Ports are already in use by another service.
  • Insufficient permissions on certificate files.
  • Missing certificate files.

Issue 2. 503 Service Unavailable Errors: Indicates no healthy backend servers available:

Bash
# Check backend server statusecho "show stat" | sudo socat stdio /var/run/haproxy/admin.sock | grep backend_name # View real-time logssudo tail -f /var/log/haproxy/haproxy.log

Solutions:

  • Verify backend servers are running and accessible.
  • Check that the health check configuration matches the application requirements.
  • Review firewall rules between HAProxy and backends.
  • Verify SSL certificate validity if using SSL health checks.

Issue 3. Connection Timeouts: Review and adjust timeout settings:

Bash
# Check for timeout patterns in logssudo tail -f /var/log/haproxy/haproxy.log | grep -E "(cR|sR|CT|ST)"

Common timeout flags:

  • cR: Client timeout on receive.
  • sR: Server timeout on receive.
  • CT: Client timeout.
  • ST: Server timeout.

Adjust relevant timeout values in the configuration based on application requirements.

Issue 4. SSL/TLS Handshake Failures: Verify certificate configuration:

Bash
# Test SSL certificateopenssl s_client -connect your-server:443 -servername your-domain.com # Check certificate expirationopenssl x509 -in /etc/haproxy/certs/example.com.pem -noout -dates # Verify certificate chainopenssl verify -CAfile /etc/ssl/certs/ca-certificates.crt /etc/haproxy/certs/example.com.pem

Common causes:

  • Incomplete certificate chain.
  • Expired certificates.
  • Incorrect file permissions.
  • Missing intermediate certificates.

Conclusion

HAProxy is fast, flexible, and has many features, so it works well for everything from small projects to huge websites. If you use the setup examples and best practices in this guide, you can build a reverse proxy that is stable, secure, and able to handle very large traffic with very low delay.

We hope you enjoy this guide. Subscribe to our X and Facebook channels to get the latest updates and articles.

For further reading:

Build a Highly Available VMware ESXi Cluster

Configuring Automatic LetsEncrypt SSL Certificate Renewal

Use HTTP mode for websites and APIs because it supports routing by host, path, headers, redirects, and Layer 7 features. Use TCP mode for non-HTTP services.

Put it in /etc/haproxy/haproxy.cfg after global and defaults, and before backend sections.

Most of the time, it means HAProxy thinks all backends are DOWN, health check failing, or network access blocked.

Prev PostHow to Set Up HashiCorp Vault on a VPS: TLS, Policies, and Backups
Next PostHigh-Performance Linux Networking: Kernel and sysctl Tuning Tutorial
Category:Server Applications & Stacks
Tag:

We use cookies to run PerLod and to understand how the site is used. You can accept everything, or open Manage to turn individual categories off. Cookie policy.
